Disassembling Fisher-Price Laugh and Learn Smart Stages Sis (JCT11, 2024)

Open the hook and loop fastener at the back.

Put the switch to the top-most position to switch off the device.

Unscrew two screws located at the bottom of plastic chassis.

Carefully lift the plastic cover of the chassis. Watch out to not break thin wires connected to the cover.

Remove plastic switch.

Unscrew the screw located in the center of the power control unit.

Lift the power control unit and unplug red plug from the socket. To release the plug you will need to lever up small locking latch.

You will need to remove plastic bar which is holding the speaker. To do so you will need to flatten plastic lockpin which is holding the bar. You may use pliers to flatten the lockpin.

Then you can lever up the plastic bar and shift the speaker aside.

Now you will need to unlock four plastic latches which connect the front panel with the internal chassis.

To open each latch you may use flat screw driver to leaver up the locking mechanism. At the same time pull the front panel apart.

Once all four latches are released you may remove the front panel and take out the plastic chassis.

In order to disassembly the front panel unscrew four screws.

To assembly the toy just repeat all steps in the reverse order :)

Please note that all parts have marking arrows which should be pointing up when assembling the toy.
