ASRock B850 Labels

Publicado em: 13/07/25

Teardown

Introdução

  1. WjTxgETX6EEHG5Zo

    • Top of mobo

    • Bottom of mobo

  2. mgH5ukULHKJH2Svg
    mgH5ukULHKJH2Svg
    wS21pFBpXbSgcSVt

    • CPU fan connectors

    • CPU goes here

    • SSD cover

    • CMOS battery

    • Wifi chip

    • Ram slots

  3. a6JBYai35DrqTc2l
    a6JBYai35DrqTc2l
    SVgVqGGsrSVkiCfh

    • Chassis fan connectors

    • Heatsink goes here (After CPU is installed)

    • ATX12V1 port

    • ATX12V2 port

  4. SEgwhBJ1EyNeLxh2
    SEgwhBJ1EyNeLxh2
    2jNBSLRJEUgZRhUX

    • AIO Pump

    • ADDR LED

    • Graphics card goes here

  5. RcJoXCeFvyNW5ivT
    RcJoXCeFvyNW5ivT
    6ijwRGo4OAyqxtpv

    • Channel A1

    • Channel A2

    • Channel B1

    • Channel B2

    • If you only have 2 sticks of RAM, you should use channels A2 and B2 to avoid any errors

  6. rXNPEcCXDTOor2Xx

    • Display port

    • HDMI port

    • USB-C port

    • Ethernet port

    • USB 2.0 and 3.0 ports

    • Antenna plugs in here
